CS-12 Series 2,2,4-Trimethyl-1,3-Pentanediol Monoisobutyrate
RAW MATERIAL
CS-12

CS-12 Series 2,2,4-Trimethyl-1,3-Pentanediol Monoisobutyrate

CS-12 Series 2,2,4-Trimethyl-1,3-Pentanediol Monoisobutyrate is a colorless, low-volatility coalescing solvent used to support film formation in water-based coating systems.

Chemical Name
2,2,4-Trimethyl-1,3-Pentanediol monoisobutyrate
Molecular Weight
216.3 g/mol
Molecular Formula
C12H24O3
EINECS
2010492
PRODUCT OVERVIEW

Product Description

CS-12 Series 2,2,4-Trimethyl-1,3-Pentanediol Monoisobutyrate is a colorless and transparent diol ester liquid used primarily as a coalescing and film-forming aid in water-based systems. It combines low volatility, a high boiling point, and a low freezing point, making it suitable for emulsion polymer and coating formulations where efficient film formation is required. CS-12 helps reduce the minimum film-forming temperature of emulsion systems and supports the formation of stable, uniform films in applications such as latex paints, adhesives, emulsions, and architectural coatings.
PRODUCT PARAMETERS

General Parameters

Appearance
Colorless transparent liquid
KEY PROPERTIES

Product Characteristics

Colorless and transparent liquid.
Low-volatility, high-boiling diol ester solvent.
Effective coalescing and film-forming aid for water-based systems.
Helps reduce the minimum film-forming temperature of emulsion systems.
TECHNICAL SPECIFICATIONS

Specification Data

Specification Standard
Appearance Colorless transparent liquid
Chromaticity / Hazen Unit (Platinum-Cobalt Scale) 15 max
Acidity by mgKOH/g 0.20 max
Moisture by wt % 0.10 max
Density (ρ20°C) by g/cm³ 0.945-0.955
Ester Content by wt % 98.50 min
APPLICATIONS

Typical Uses

Used as a coalescing and film-forming aid in water-based emulsion coatings.
Suitable for latex paints, adhesives, emulsions, and building coating systems.
Helps reduce minimum film-forming temperature and supports improved film formation and coating performance.
STORAGE & HANDLING

Handling Guidance

Store in a cool, dry, and well-ventilated area in suitable sealed packaging. Protect the product from contamination and incompatible materials. Storage and handling requirements should follow the applicable supplier SDS, COA, and technical documentation.
PRODUCT INQUIRY

Request product information.

Share your required specification, quantity, application, and delivery destination.
